Details

The unique design of the V-Force reed valve system features double the reed tip surface over a conventional reed valve design. This has two major benefits: 1) The reed petals only travel half the distance as a conventional reed valve design to get the same airflow. 2) Because the reed petals only need to travel half the distance of that on a conventional reed valve design, there is a greater chance of them being fully opened as well as a better chance of sealing when they are "closed". A reed petal never truly "closes" in a classic sense, as it is always in movement. Consider this, an engine operating at 8,000 RPM results in a reed petal opening and closing 133 times in one second. This fact, sheds light on another V-Force advantage. Since the petals are only traveling half the distance, they generally last longer and they receive less wear than the reed petals on a conventional reed valve design.

• Reed petal resin system, carbon fiber and lay-up.
• Pre-curved reed petal ensures better seal at tip.
• Wider reed cage for maximum airflow.
• Combined reed tip area increased by 10.5% resulting in increased total air flow.
• Airfoil shape added to cage tip to increase air velocity from outer ports.
• Long reed stops added to progressively slow petal tip velocity, for increased petal durability.
• Reduced frontal area of central wing by 15.6% combined with a more aerodynamic shape.

• Rubber overmodling on reed tip surface of cage to further enhance petal life.
• All-new manifold, reed cage and air guide designed for the VFVorce4R.
